7 Preparing the configuration device #

The pre-built images are delivered with a default partitioning scheme, which can be changed during the first boot by using Ignition or Combustion. For a procedure to repartition the system, refer to Section 7.2.1, “config.ign” or Section 7.3.1, “The script configuration file”.

Important: Btrfs is mandatory for the root file system

If you intend to perform any changes to the default partitioning scheme, the root file system must be Btrfs.

Each image has the following subvolumes:

 /home
 /root
 /opt
 /srv
 /usr/local
 /var

The images also have mounted subvolumes for booting by default. The specific subvolumes differ according to the architecture.

The /etc directory is mounted as OverlayFS, where the upper directory is mounted to /var/lib/overlay/1/etc/. For details, refer to Book “Administration Guide”, Chapter 1 “Read-only file system”, Section 1.1 “/etc on a read-only file system”.

You can recognize the subvolumes mounted by default by the option x-initrd.mount in /etc/fstab. Other subvolumes or partitions must be configured either by Ignition or Combustion.

Ignition is a provisioning tool that enables you to configure a system according to your specification on the first boot. When the system is booted for the first time, Ignition is loaded as part of an initramfs and searches for a configuration file within a specific directory (on a USB flash drive, or you can provide a URL). All changes are performed before the kernel switches from the temporal file system to the real root file system (before the switch_root command is issued).

Ignition uses a configuration file in the JSON format. The file is called config.ign.

7.2.1 config.ign #



config.ign is a JSON configuration file that provides prescriptions for Ignition. You can either create the file manually in JSON, or you can use the Fuel Ignition tool (https://opensuse.github.io/fuel-ignition/) to generate a basic set of prescriptions. Bear in mind that the Fuel Ignition tool does not provide a full set of options, so you might have to modify the file manually.

When installing on bare metal, the configuration file config.ign must reside in the ignition subdirectory on the configuration media labeled ignition. The directory structure must look as follows:

<root directory>
└── ignition
  └── config.ign

If you intend to configure a QEMU/KVM virtual machine, provide the path to config.ign as an attribute of the qemu command. For example:

-fw_cfg name=opt/com.coreos/config,file=PATH_TO_config.ign

When configuring a virtual machine with Virtual Machine Manager (libvirt), provide the path to the config.ign file in its XML definition, for example:

<domain ... >
<sysinfo type="fwcfg">
<entry name="opt/com.coreos/config" file="/location/to/config.ign"/>
</sysinfo>
</domain>

Alternatively, when using libvirt, you can provide the path as an option to the virt-install command:

--sysinfo type=fwcfg,entry0.name="opt/com.coreos/config",entry0.file="PATH_TO_config.ign>"

The config.ign file contains various data types: objects, strings, integers, Booleans and lists of objects. For a complete specification, refer to Ignition specification v3.3.0.

The version attribute is mandatory, and with SLE Micro, its value must be set either to 3.3.0 or to any lower version. Otherwise Ignition will fail.

To log in to your system as root, you must at least include a password for root. However, it is recommended to establish access via SSH keys. If you want to configure a password, make sure to use a secure one. If you use a randomly generated password, use at least 10 characters. If you create your password manually, use even more than 10 characters and combine uppercase and lowercase letters and numbers.

7.2.1.1 Configuration examples #



This section will provide you with some common examples of the Ignition configuration in the JSON format.

Important: Declaring content outside the default subvolumes

Bear in mind that if you want to create files outside the default mounted directories, you need to define the directories using the filesystem attribute.

Note: The version attribute is mandatory

Include the version specification in config.ign (version 3.3.0 or lower).

7.2.1.1.1 Storage configuration #



The storage attribute is used to configure partitions and RAID, define file systems, create files, etc. To define partitions, use the disks attribute. The filesystem attribute is used to format partitions. The files attribute can be used to create files in the file system. Each of the mentioned attributes is described in the following sections.

7.2.1.1.1.1 The disks attribute #



The disks attribute is a list of devices that enables you to define partitions on these devices. The disks attribute must contain at least one device. Other attributes are optional. The following example will use a single virtual device and divide the disk into four partitions:

  {
  "variant": "fcos",
  "version": "3.3.0",
  "storage": {
      "disks": [
          {
              "device": "/dev/vda",
              "wipe_table": true,
              "partitions": [
                  {
                      "label": "root",
                      "number": 1,
                      "type_guid": "4F68BCE3-E8CD-4DB1-96E7-FBCAF984B709"
                  },
                  {
                      "label": "boot",
                      "number": 2,
                      "type_guid": "BC13C2FF-59E6-4262-A352-B275FD6F7172"
                  },
                  {
                      "label": "swap",
                      "number": 3,
                      "type_guid": "0657FD6D-A4AB-43C4-84E5-0933C84B4F4F"
                  },
                  {
                      "label": "home",
                      "number": 4,
                      "type_guid": "933AC7E1-2EB4-4F13-B844-0E14E2AEF915"
                  }
              ]
          }
      ]
  }
}

7.2.1.1.1.2 The raid attribute #



The raid is a list of RAID arrays. The following attributes of raid are mandatory:

level

a level of the particular RAID array (linear, raid0, raid1, raid2, raid3, raid4, raid5, raid6)

devices

a list of devices in the array referenced by their absolute paths

name

a name that will be used for the md device

    {
  "variant": "fcos",
  "version": "3.3.0",
  "storage": {
      "raid": [
          {
              "name": "system",
              "level": "raid1",
              "devices": [
                  "/dev/sda",
                  "/dev/sdb"
              ]
          }
      ]
  }
}

7.2.1.1.1.3 The filesystem attribute #



Note: Ignition does not perform modifications to mount units

The file system attribute does not modify mount units. If you add a new partition or remove an existing partition, you must manually adjust the mount units.

filesystem must contain the following attributes:

device

the absolute path to the device, typically /dev/sda in case of physical disk

format

the file system format (btrfs, ext4, xfs, vfat or swap)

Note

In the case of SLE Micro, the root file system must be formatted to Btrfs.

The following example demonstrates using the filesystem attribute. The /opt directory will be mounted to the /dev/sda1 partition, which is formatted to Btrfs. The partition table will not be erased.

{
  "variant": "fcos",
  "version": "3.3.0",
  "storage": {
      "filesystems": [
          {
              "path": "/opt",
              "device": "/dev/sda1",
              "format": "btrfs",
              "wipe_filesystem": false
          }
      ]
  }
}

7.2.1.1.1.4 The files attribute #



You can use the files attribute to create any files on your machine. Bear in mind that if you want to create files outside the default mounted directories, you need to define the directories by using the filesystem attribute.

In the following example, a host name is created by using the files attribute. The file /etc/hostname will be created with the slemicro-1 host name.

Note: Decimal numeral systems in JSON

Bear in mind that JSON uses the decimal numeral system, so the mode value is a decimal notation of the access rights.

{
  "variant": "fcos",
  "version": "3.3.0",
  "storage": {
      "files": [
          {
              "path": "/etc/hostname",
              "mode": 420,
              "overwrite": true,
              "contents": {
                  "inline": "slemicro-1"
              }
          }
      ]
  }
}

7.2.1.1.1.5 The directories attribute #



The directories attribute is a list of directories that will be created in the file system. The directories attribute must contain at least one path attribute.

{
  "variant": "fcos",
  "version": "3.3.0",
  "storage": {
      "directories": [
          {
              "path": "/mnt/backup",
              "user": {
                  "name": "tux"
              }
          }
      ]
  }
}

7.2.1.1.2 Users administration #



The passwd attribute is used to add users. If you intend to log in to your system, create root and set the root's password and/or add the SSH key to the Ignition configuration. You need to hash the root password, for example, by using the openssl command:

openssl passwd -6

The command creates a hash of the password you chose. Use this hash as the value of the password_hash attribute.

The users attribute must contain at least one name attribute. ssh_authorized_keys is a list of SSH keys for the user.

Note: Creating other users than root

When you are creating other users than root, you need to define /home directories for the users, because these directories (usually /home/USER_NAME) are not mounted by default. Therefore, declare these directories using the storage/filesystem attribute. For example, for tux, the example looks as follows:

      {
"ignition": {
  "version": "3.2.0"
},
"passwd": {
  "users": [
    {
      "name": "tux",
      "passwordHash": "$2a$10$US9XSqLOqMmGq/OnhlVjPOwuZREh2.iEtlwD5LI7DKgV24NJU.wO6"
    }
  ]
},
"storage": {
  "filesystems": [
    {
      "device": "/dev/disk/by-label/ROOT",
      "format": "btrfs",
      "mountOptions": [
        "subvol=/@/home"
      ],
      "path": "/home",
      "wipeFilesystem": false
    }
  ]
}
}

7.2.1.1.3 Enabling systemd services #



You can enable systemd services by specifying them in the systemd attribute. The name must be the exact name of a service to be enabled (including the suffix).

{
"ignition": {
  "version": "3.0.0"
},
"systemd": {
  "units": [
    {
      "enabled": true,
      "name": "sshd.service"
    }
  ]
}
}

Combustion is a dracut module that enables you to configure your system on its first boot. Combustion reads a provided file called script and executes commands in it and thus performs changes to the file system. You can use Combustion to change the default partitions, set users' passwords, create files, install packages, etc.

The Combustion dracut module is invoked after the ignition.firstboot argument is passed to the kernel command line. Combustion then reads the configuration from script. Combustion tries to configure the network if the network flag has been found in script. After /sysroot is mounted, Combustion tries to activate all mount points in /etc/fstab and then call transactional-update to apply other changes (like setting root password or installing packages).

When using Combustion, you need to label the configuration device with the name combustion, create a specific directory structure in that configuration medium, and include a configuration file named script. In the root directory of the configuration medium, create a directory called combustion and place the script into this directory along with other files—SSH key, configuration files, etc. The directory structure then should look as follows:

<root directory>
└── combustion
    └── script
    └── other files

You can use Combustion to configure your QEMU/KVM virtual machine. In this case, pass the location of the script file using the fw_cfg parameter of the qemu command:

-fw_cfg name=opt/org.opensuse.combustion/script,file=/var/combustion-script

When configuring a virtual machine with Virtual Machine Manager (libvirt), provide the path to the script file in its XML definition, for example:

<domain ... >
<sysinfo type="fwcfg">
<entry name="opt/org.opensuse.combustion/script" file="/location/of/script"/>
</sysinfo>
</domain>

Alternatively, when using libvirt, you can provide the path as an option to the virt-install command:

--sysinfo type=fwcfg,entry0.name="opt/org.opensuse.combustion/script",entry0.file="PATH_TO_script>"

Combustion can be used along with Ignition. If you intend to do so, label your configuration medium ignition and include the ignition directory with the config.ign to your directory structure, as shown below:

<root directory>
└── combustion
    └── script
    └── other files
└── ignition
    └── config.ign

In this scenario, Ignition runs before Combustion.

7.3.1 The script configuration file #



The script configuration file is a set of commands that are executed on your system in a transactional-update shell. This section provides examples for performing various configuration tasks by using Combustion.

Important: Include interpreter declaration

As the script file is interpreted by shell, start the file with the interpreter declaration on the first line. For example, for Bash:

 #!/bin/bash

To log in to your system, include at least the root password. However, it is recommended to establish the authentication using SSH keys. If you need to use a root password, make sure to configure a secure password. If you use a randomly generated password, use at least 10 characters. If you create your password manually, use even more than 10 characters and combine uppercase and lowercase letters, and numbers.

7.3.1.1 Network configuration #



To configure and use the network connection during the first boot, add the following statement to your script:

 # combustion: network

Using this statement will pass the rd.neednet=1 argument to dracut. If you do not use the statement, the system will be configured without any network connection.

7.3.1.2 Performing modifications in the initramfs #



You may need to perform changes to the initramfs environment, for example, to write a custom network configuration for NetworkManager into /etc/NetworkManager/system-connections/. To do so, use the prepare statement.

For example, to create a connection with a static IP address and configure DNS:

#!/bin/bash
# combustion: network prepare
set -euxo pipefail

nm_config() {
umask 077 # Required for NM config
mkdir -p /etc/NetworkManager/system-connections/
cat >/etc/NetworkManager/system-connections/static.nmconnection <<-EOF
[connection]
id=static
type=ethernet
autoconnect=true

[ipv4]
method=manual
dns=192.168.100.1
address1=192.168.100.42/24,192.168.100.1
EOF
}

if [ "${1-}" = "--prepare" ]; then
nm_config # Configure NM in the initrd
exit 0
fi

# Redirect output to the console
exec > >(exec tee -a /dev/tty0) 2>&1

nm_config # Configure NM in the system
curl example.com

# Close outputs and wait for tee to finish
exec 1>&- 2>&-; wait;

# Leave a marker
echo "Configured with combustion" > /etc/issue.d/combustion

7.3.1.3 Waiting for the task to complete #



Some processes may be run in background, for example, the tee process that redirects output to the terminal. To ensure that all running processes are completed before the script execution finishes, add the following line:

exec 1>&- 2>&-; wait;

7.3.1.4 Partitioning #



SLE Micro raw images are delivered with a default partitioning scheme as described in Section 7.1, “Default partitioning”. You might want to use a different partitioning. The following set of example snippets moves the /home to a different partition.

Note: Performing changes outside of directories included in snapshots

The following script performs changes that are not included in snapshots. If the script fails and the snapshot is discarded, some changes remain visible and cannot be reverted (like the changes to the /dev/vdb device.)

The following snippet creates a GPT with a single partition on the /dev/vdb device:

sfdisk /dev/vdb <<EOF
label: gpt
type=linux
EOF

partition=/dev/vdb1

As the sfdisk command may take longer time to complete, postpone label by using the sleep command after sfdisk.

The partition is formatted to Btrfs:

wipefs --all ${partition}
mkfs.btrfs ${partition}

Possible content of /home is moved to the new /home folder location by the following snippet:

mount /home
mount ${partition} /mnt
rsync -aAXP /home/ /mnt/
umount /home /mnt

The snippet below removes an old entry in /etc/fstab and creates a new entry:

awk -i inplace '$2 != "/home"' /etc/fstab
echo "$(blkid -o export ${partition} | grep ^UUID=) /home btrfs defaults 0 0" >>/etc/fstab

7.3.1.5 Setting a password for root #



Before you set the root password, generate a hash of the password, for example, by using the openssl passwd -6. To set the password, add the following to your script:

 echo 'root:$5$.wn2BZHlEJ5R3B1C$TAHEchlU.h2tvfOpOki54NaHpGYKwdNhjaBuSpDotD7' | chpasswd -e

7.3.1.6 Adding SSH keys #



The following snippet creates a directory to store the root's SSH key and then copies the public SSH key located on the configuration device to the authorized_keys file.

 mkdir -pm700 /root/.ssh/
cat id_rsa_new.pub >> /root/.ssh/authorized_keys

Note

The SSH service must be enabled in case you need to use remote login via SSH. For details, refer to Section 7.3.1.7, “Enabling services”.

7.3.1.7 Enabling services #



You may need to enable some services, for example, the SSH service. To enable the SSH service, add the following line to script:

 systemctl enable sshd.service

7.3.1.8 Installing packages #



Important: Network connection and registering your system might be necessary

As some packages may require additional subscription, you might need to register your system beforehand. An available network connection may also be needed to install additional packages.

During the first boot configuration, you can install additional packages to your system. For example, you can install the vim editor by adding:

zypper --non-interactive install vim-small

Note

Bear in mind that you cannot use zypper after the configuration is complete and you boot to the configured system. To perform changes later, you must use the transactional-update command to create a changed snapshot. For details, refer to Book “Administration Guide”, Chapter 3 “Administration using transactional updates”.

To prepare the raw image, proceed as follows:

If you do not attach any configuration device when booting the raw image for the first time, jeos-firstboot enables you to perform minimal configuration of your system as follows:
